Eaton Wheel Studs for Single Rear Wheel Axle conversion from drum to disc

Eaton Wheel Studs for Single Rear Wheel Disc Brake Conversion – 16 Pack

$80.00

  • These studs are used when converting 8 lug single rear wheel Eaton axles with 1/2″ wheel studs from drum to disc
  • Set of 16 Studs
  • Press-In
  • Right Hand Thread
SKU: eat-stds Category:

Description

These Eaton wheel studs are used when converting 8 lug single rear wheel Eaton axles with 1/2″ wheel studs from drum to disc. Originally, these axles had a slide-on drum. When converting to disc brakes the rotor goes behind the hub, so they need a stud with a longer knurl.

Eaton Wheel Stud Specifications:

Color: Silver
Head Diameter: 0.725 in
Knurl Diameter (In): 0.561 in
Material: Steel
Package Contents: 16 Studs
Quick-Start Nose: No
SAE or Metric: SAE
Shoulder Length (In): 1.875 in
Style: Serrated Stud
Thread Diameter: 1/2 in
Thread Direction: Clockwise (Right)
Thread Length (In): 2.845 in
Thread Size: 1/2-20
Threads Per Inch: 20
Under Head Length: 2.875 in

Note: These may fit other vehicles, but the intended fit is for Eaton Single Rear Axles when converted from drum to disc brakes using our kit.
